Legend Suspension REVO-A Adjustable XL Coil Suspension 2002-2006 Harley-Davidson 1200 Custom EFI XLC Clear Anodized Standard 13″

Description

Part Notes: Heavy Duty application is recommended for 500 lb+ rider and passenger total weight. Does not fit Sportster Super Low. Does not fit Sportster S (RH1250). Does not fit Sportster Nightster (RH975).

Features:

Available in Black, Gold, and Clear Type III hard coat anodize

Legend’s touring specific coil spring rates provide superior ride comfort, improved performance, and increased resistance to bottoming for all day comfort

Adjusts by hand, no tools needed

Available in 12″, 13″, and 14″, standard or heavy-duty applications

Easy installation and alignment, provided by spherical bearings on both top and bottom mounting points

All the benefits of the REVO shocks above plus six external knob adjustments allow fine-tuning of rebound

Provides optimum rebound performance for any given rider weight, personal ride quality preference, or personal riding style

Light to heavy riders can fine-tune ride preference

Aggressive to casual riding styles can tune to desired quality or personal preference

Made by hand in Sturgis, SD USA

Specifications:

Adjustment Type: Adjustable Rebound Damping

Mounting Position: Rear

Reservoir Location: Internal

Riding Style: Street

Model: Revo-A

Damping Method: Deflective Disc

Type: Coilover Twin-Tube

Duty: Standard

Product Name: Shock Absorber

Units: Pair

Color/Finish: Anodized / Clear

Extended Length: 13.00″

Material: Hard Anodized Machined Aluminum

Fitment:
